    Relay Lenses

    Relay Lenses are used to extend imaging systems or invert images for use in a range of imaging applications including microscopy, inspection, or life sciences. Relay Lenses use arrays or imaging lenses placed behind eyepieces to extend the length of imaging systems, such as in microscopes, endoscopes, or where proximity to a viewed object is not feasible. Relay Lenses may also be used to invert an image behind the eyepiece of an imaging system for proper viewing. Relay Lenses are available in a wide range of options suited to a number of relay needs.

    C-Mount Achromatic Pairs
    • C-Mount Designs for Easy Integration into Imaging Applications
    • Feature Integrated Iris for Increased Control of Light Throughput
    • Ideal for Relay or Projection Applications

    Mounted Achromatic Lens Pairs
    • 15mm and 30mm Diameter Options
    • AR Coated Lenses
    • Mounted Achromatic Pairs Kits Available

    Mounted Near-IR (NIR) Achromatic Lens Pairs
    • 30mm Diameter Package Designed for NIR Applications
    • Optimized for Various Magnification Ratios
    • Ideal for Integration into OEM Applications
    • NIR II Coated for 750-1550nm

    Relay Lenses
    • Optimized for 1:1 Imaging
    • f/4 and f/8 Versions Available

    Specific Microscope Video Relay Lenses
    • Video Adaptability for Most Microscopes
    • Offer High Resolution and Precise Focusing
    • Permit Variety of Magnifications
    • Interchangeable—Share Video Cameras and Coupler with Many Different Microscopes

    Steinheil Triplet Achromatic Lenses
