    Broadband Laser Mirrors

    Broadband Laser Mirrors provide high reflectivity over a broad range of wavelengths, optimizing versatility for laser systems with multiple lasers, unusual wavelengths, or tunable laser sources. These mirrors are coated with either dielectric coatings covering most dye, diode, Ti:sapphire, Nd:YAG, and fiber laser sources or metallic coatings for applications requiring a more expansive reflectivity range. Broadband Laser Mirrors feature high surface quality and thermally-stable fused silica substrates, minimizing both scattering and thermal effects when used with lasers.

    Edmund Optics offers flat Broadband Laser Mirrors with angles of incidence from 0 o to 45o, as well as specialty options for applications from the UV to the IR. TECHSPEC Broadband Dielectric Laser Mirrors are available in UV, VIS, and NIR versions with >98% reflectivity at their design wavelength range. Broadband Dielectric Coated Right Angle Mirrors are offered with similar performance for easy mounting integration into laser systems. For Deep UV (DUV) and Vacuum UV (VUV) applications, Precision Ultraviolet Mirrors provide excellent reflection with aluminum-based coatings to minimize sensitivity to polarization. Knife-Edge Pickoff Mirrors coated with enhanced aluminum, protected gold, or protected silver are also available for separating closely propagating laser beams.

    Broadband Dielectric λ/10 Mirrors
    • Greater Than 99% Reflection Over Broad Wavelength Ranges
    • Designed for all Polarization States from 0 – 45° AOI
    • Excellent Thermal Stability due to Fused Silica Substrate

    2μm Highly-Dispersive Broadband Ultrafast Mirrors
    • Reflectivity >99.9% Between 2000 - 2200nm
    • GDD of -1000fs2 @ 5° AOI
    • Ideal for <100fs Pulse Compression of Thulium and Holmium Lasers
    • Broadband Ultrafast Chirped Coating


    1030nm Highly-Dispersive Broadband Ultrafast Mirrors
    • Negative GDD of -200 fs2 at 5° AOI
    • >99.8% Reflection (p-polarization) between 950 - 1120nm
    • Designed for Pulse Compression of Yb:doped Fiber Lasers
    • Broadband Ultrafast Chirped Coating

    45° AOI Ultrafast Chirped Mirrors
    • High Reflectivity and Negative Group Delay Dispersion (GDD)
    • Ideal for Dispersion Compensation and Beam Compression @ 45° AOI
    • Designs for Femtosecond Lasers, including Ti:sapphire

    Precision Ultraviolet Mirrors
    • 120nm and 190nm Design Wavelengths
    • Average Reflectivity >85% Across Specified Range
    • Enhanced Metallic Coatings for Broadband Reflectivity through the Visible Region

    Precision Broadband Laser Mirrors
    • Ideal for Tunable Lasers and Reflecting Multiple Laser Sources
    • High Reflectivity from 0 - 45° for All Polarization States
    • Variety of Coating Options Available

    Ultrafast Broadband Laser Mirrors
    • >99% Reflectivity
    • High Performance over 70-140nm Wavelength Ranges
    • Cost-Competitive Solutions with <40 fs2 GDD @ CWL
    • Ultrafast Laser Line Mirrors Also Available

    Knife-Edge Pickoff Mirrors
    • Designed to Separate Two Beams Propagating Closely Next to Each Other
    • 45° Bevel
    • Coating Aperture Up to the Knife-Edge
    • Enhanced Aluminum, Protected Gold and Protected Silver Coating Options

    Broadband Dielectric Coated Right Angle Mirrors
